温度因素对盆式绝缘子缺陷电场分布影响的仿真研究

顾媛丽; 康朝阳; 王绪亮; 韩克俊; 刘洪顺; 李清泉

doi:10.13296/j.1001-1609.hva.2026.06.019

您当前的位置：

首页 >

文章列表页 >

温度因素对盆式绝缘子缺陷电场分布影响的仿真研究

研究与分析 | 更新时间：2026-06-10

- 温度因素对盆式绝缘子缺陷电场分布影响的仿真研究
- Simulation Study on the Influence of Temperature Factors on the Electric Field Distribution of Defects in Insulating Spacers
- 高压电器 2026年62卷第6期页码：155-162
- 作者机构：

  山东大学特高压输变电技术与装备山东省重点实验室，济南 250061
  山东电工电气集团有限公司，济南 250101
- 作者简介：

  顾媛丽（1998—），女，硕士研究生，主要研究方向为GIS绝缘缺陷特性研究（E-mail：903364597@qq.com）。
  李清泉（1969—），男，教授，博导，主要研究方向为高压设备复合绝缘的放电特性、绝缘的劣化机理、绝缘状态评估、人工智能在电力设备中的应用（通信作者）（E-mail：lqq@sdu.edu.cn）。
- 基金信息：

  山东省重点研发计划（重大科技创新项目）;Shandong Province Key R&D Program (Major Science and Technology Innovation Project)(2021CXGC010211)
- DOI：10.13296/j.1001-1609.hva.2026.06.019
  中图分类号：
- 收稿：2025-11-18，

  修回：2026-02-11，

  纸质出版：2026-06-16
- 稿件说明：
移动端阅览
顾媛丽, 康朝阳, 王绪亮, 等. 温度因素对盆式绝缘子缺陷电场分布影响的仿真研究[J]. 高压电器, 2026,62(6):155-162.

GU Yuanli, KANG Zhaoyang, WANG Xuliang, et al. Simulation Study on the Influence of Temperature Factors on the Electric Field Distribution of Defects in Insulating Spacers[J]. High Voltage Apparatus, 2026, 62(6): 155-162.
顾媛丽, 康朝阳, 王绪亮, 等. 温度因素对盆式绝缘子缺陷电场分布影响的仿真研究[J]. 高压电器, 2026,62(6):155-162. DOI： 10.13296/j.1001-1609.hva.2026.06.019.

GU Yuanli, KANG Zhaoyang, WANG Xuliang, et al. Simulation Study on the Influence of Temperature Factors on the Electric Field Distribution of Defects in Insulating Spacers[J]. High Voltage Apparatus, 2026, 62(6): 155-162. DOI： 10.13296/j.1001-1609.hva.2026.06.019.

摘要

温度是影响气体绝缘金属封闭组合电器（GIS）中典型绝缘缺陷形成与发展的重要因素之一。为探究温度因素对盆式绝缘子缺陷电场分布的影响，文中利用有限元软件建立了252 kV GIS电—热—流多物理场耦合模型，得到了不同导体温度下、处于不同位置的气泡、裂纹及悬浮金属微粒缺陷下绝缘子表面的电场分布，并通过表面电荷分布与计算气体临界击穿场强进一步分析电场变化规律。结果表明：导体温度升高，3种缺陷下的绝缘子表面最大场强都随之增大，裂纹缺陷下增幅最大，悬浮金属微粒下最小。温度变化对电场的影响与绝缘缺陷类型、位置有关。导体温度越高，悬浮金属微粒周围与位于低压侧的气泡、裂纹处的绝缘子表面电场强度逐渐增大，而高压侧的气泡及裂纹处的绝缘子表面电场强度逐渐减小。位于低压侧的绝缘缺陷电荷密度随温度变化更加明显，电场畸变幅值改变也更大。研究结果有助于进一步认识温度变化对气泡、裂纹、悬浮金属微粒缺陷下盆式绝缘子表面电场分布的影响规律，对绝缘子设计改进也有一定的参考价值。

Abstract

Temperature is one of the important factors affecting the formation and development of typical insulation defects in gas insulated switchgear (GIS) . For exploring the influence of temperature factors on the electric field distribution of defects on the insulating spacers

a 252 kV GIS electric-thermal-fluid multi-physical field coupling model is set up in this paper by using finite element software

and the electric field distributions on the spacer surface are obtained for different conductor temperatures

bubbles

cracks

and suspended metal particle defects in different locations

and the variation of electric field is analyzed further by the space surface charge distribution and calculation of critical breakdown field strength of gas. The results show that with the increase of conductor temperature the maximum field strength on the spacer surface increases accordingly under all three defects

with maximum increase under crack defect and minimum increase under suspended metal particles. The effect of temperature change on the electric field is related to the type and location of the insulation defects. The higher the temperature of the conductor

the electric field strength of the spacer surface around the suspended metal particles and the bubbles as well as cracks on the low-voltage side gradually increases

while the electric field strength of the spacer surface at the bubbles and cracks on the high-voltage side gradually decreases. The charge density of insulation defects on the low voltage side varies more significantly with temperature variation

and the electric field distortion ampli tude changes more significantly. The study results can be not onlyuseful for further understanding the effect of temperature variation on the electrical field distribution on the surface of insualtign spacer under bubbles

cracks and suspended metal particles defects

but also have some reference value for design improvement of the insulating spacer.

关键词

Keywords

references

岳嵩,朱勇,何龙寿,等.基于改进动态电弧模型的GIS快速暂态过电压特性研究[J].智慧电力,2025,53(8):114-120.

YUE Song, ZHU Yong, HE Longshou, et al.Research on characteristics of very fast transient overvoltage in GIS based on an improved dynamic arc model[J]. Smart Power,2025,53(8):114-120.

王宁,黄新波,朱永灿,等.基于MA-DBN算法的GIS故障预测[J].西安工程大学学报,2020,34(5):27-33.

WANG Ning, HUANG Xinbo, ZHU Yongcan, et al.GIS fault prediction based on MA-DBN algorithm[J]. Journal of Xi'an Polytechnic University,2020,34(5):27-33.

XING Yunqi, WANG Zhiwen, LIU Lin, et al. Defects and failure types of solid insulation in gas-insulated switchgear:In situ study and case analysis[J]. High Voltage,2022,7(1):158-164.

周倩,唐炬,唐铭,等.GIS内4种典型缺陷的局部放电超高频数学模型构建[J].中国电机工程学报,2006,26(8):99-105.

ZHOU Qian, TANG Ju, TANG Ming, et al.Mathematical model of four typical defects for UHF partial discharge in GIS[J]. Proceedings of the CSEE,2006,26(8):99-105.

王浩然,郭子豪,张丝钰,等.缺陷对特高压交流盆式绝缘子电场分布的影响[J].高电压技术,2018,44(3):982-992.

WANG Haoran, GUO Zihao, ZHANG Siyu, et al.Influence of UHV AC GIS spacer'defects on electrical field distribution[J]. High Voltage Engineering,2018,44(3):982-992.

刘鹏,吴泽华,朱思佳,等.缺陷对交流1100 kV GIL三支柱绝缘子电场分布影响的仿真[J].电工技术学报,2022,37(2):469-478.

LIU Peng, WU Zehua, ZHU Sijia, et al. Simulation on electric field distribution of 1100 kV AC tri-post insulator influenced by defects[J]. Transactions of China Electrotechnical Society,2022,37(2):469-478.

常文治,毕建刚,刘姝嫔,等.GIS盆式绝缘子典型缺陷的电场仿真[J].高压电器,2018,54(5):138-143.

CHANG Wenzhi, BI Jiangang, LIU Shupin, et al.Electric field simulation of GIS insulators typical defects[J]. High Voltage Apparatus,2018,54(5):138-143.

王碧霞,田铭兴,冯婷娜,等.GIS盆式绝缘子典型缺陷对其电场分布的影响[J].高压电器,2022,58(11):197-204.

WANG Bixia, TIAN Mingxing, FENG Tingna, et al.Influence of typical defects of GIS insulating spacer on its electric field distribution[J]. High Voltage Apparatus,2022,58(11):197-204.

李进,王禹淮,张黎明,等.抛光方式对交流电压下盆式绝缘子表面电荷分布和沿面闪络特性的影响[J].高电压技术, 2022,48(10):4093-4101.

LI Jin, WANG Yuhuai, ZHANG Liming, et al.Influence of polishing treatments on surface charge distribution and flashover characteristics of basin spacer under AC voltage[J]. High Voltage Engineering,2022,48(10):4093-4101.

杜伯学,姚航,梁虎成,等.时变温差工况下直流GIL/GIS盆式绝缘子动态电场畸变抑制[J].电工技术学报,2024,39(9):2851-2859.

DU Boxue, YAO Hang, LIANG Hucheng, et al.Electric field relaxation of basin spacer under variable temperature gradient in DC-GIL/GIS[J]. Transactions of China Electrotechnical Society, 2024,39(9):2851-2859.

吴细秀,程诗敏,周帆,等.母线通流温升对GIS内绝缘特性影响的仿真研究[J].高压电器,2020,56(2):7-14.

WU Xixiu, CHENG Shimin, ZHOU Fan, et al.Influence of temperature rise due to rated-current flowing through busbar on the internal insulation characteristics of GIS:A simulation study[J]. High Voltage Apparatus,2020,56(2):7-14.

王珂珂,李丽,王久阳,等.基于混合绝缘气体的三相GIS母线温升多物理场耦合机制研究[J].高压电器,2021,57(4):69-75.

WANG Keke, LI Li, WANG Jiuyang, et al.Study on multi-physical field coupling mechanism of three-phase GIS bus temperature rise based on mixed insulating gas[J]. High Voltage Apparatus,2021, 57(4):69-75.

DU B X, LIANG H C, LI J, et al.Electrical field distribution along SG 6 /N 2 filled DC-GIS/GIL epoxy spacer[J ] . IEEE Transactions on Dielectrics and Electrical Insulation,2018,25(4):1202-1210.

李进,张程,杜伯学,等.直流GIL用非线性电导环氧绝缘子电场仿真[J].高电压技术,2019,45(4):1056-1063.

LI Jin, ZHANG Cheng, DU Boxue, et al.Electrical field simulation of epoxy spacer with nonlinear conductivity forDC GIL[J]. High Voltage Engineering,2019,45(4):1056-1063.

张施令,彭宗仁,王浩然,等.盆式绝缘子多物理场耦合数值计算及结构优化[J].高电压技术,2020,46(11):3994-4005.

ZHANG Shiling, PENG Zongren, WANG Haoran, et al.Numerical calculation and structural optimization of multi-physical field coupling for basin insulator[J]. High Voltage Engineering,2020,46 (11):3994-4005.

李星,许渊,丁登伟,等.温度对GIS绝缘子表面金属异物局部放电及闪络特性的影响[J].中国电机工程学报,2022,42 (1):406-414.

LI Xing, XU Yuan, DING Dengwei, et al.Influence of temperature on partial discharge and flashover characteristics of metal particle on GIS insulator surface[J]. Proceedings of the CSEE,2022,42(1):406-414.

ZHANG Z, SONG H, MENG X, et al.Experimental research on the influence of temperature on the discharge signal of void defects in GIS[J]. High Voltage,2022,7(2):314-324.

吴吉,王增彬,吕鸿,等.考虑气流场影响的GIS温升计算与实验研究[J].高电压技术,2020,46(3):815-823.

WU Ji, WANG Zengbin, LYU Hong, et al.Calculation of GIS temperature rise considering effect of gas flow and experimental study[J]. High Voltage Engineering,2020,46(3):815-823.

杨桢,任玲玲,王凯,等.基于混合绝缘气体的GIS母线温升多物理场耦合分析[J].高压电器,2021,57(1):48-54.

YANG Zhen, REN Lingling, WANG Kai, et al.Multiphysics-field coupling analysis of GIS bus bar temperature rise based on mixed insulating gas[J]. High Voltage Apparatus,2021,57(1):48-54.

陈强,李庆民,丛浩熹,等.引入多重边界条件的GIS母线温度分布多场耦合计算及影响因素分析[J].电工技术学报, 2016,31(17):187-195.

CHEN Qiang, LI Qingmin, CONG Haoxi, et al.Numerical calculation and correlative factors analysis on temperature distribution of GIS bus bar based on coupled multi-physics methodology combined with multiple boundary conditions[J]. Transactions of China Electrotechnical Society,2016,31(17):187-195.

LUO Yi, TANG Ju, PAN Zijun, et al.How temperature and pressure affect the electric field distribution inHVDC GIS/GIL:Anumerical study[J]. IEEE Transactions on Dielectrics and Electrical Insulation,2021,28(4):1334-1342.

ZHANG Guobao, YANG Wei, CAI Mengyi, et al.Numerical computation of 3D electromagnetic heat current temperature field for UHV GIS basin insulator[C]//2020 IEEE International Conference on High Voltage Engineering and Application (ICHVE). China:IEEE,2020:1-4.

REBZANI N, CLAVEL E, MARTY P, et al.Numerical multiphysics modeling of temperature rises in gas insulated busbars[J]. IEEE Transactions on Dielectrics and Electrical Insulation,2016,23(5):2579-2586.

周宏扬,马国明,赵书静,等.温度对直流GIL绝缘子电荷积聚特性的影响[J].中国电机工程学报,2016,36(24):6675-6681.

ZHOU Hongyang, MA Guoming, ZHAO Shujing, et al.Effect of temperature on charge accumulation on insulator inDC-GIL[J]. Proceedings of the CSEE,2016,36(24):6675-6681.

阮江军,唐烈峥,邱志斌,等.基于流注起始判据的球—板—球短空气间隙击穿电压计算[J].高压电器,2017,53(7):38-44.

RUAN Jiangjun, TANG Liezheng, QIU Zhibin, et al.Breakdown voltage calculation of short sphere-plane-sphere air gap based on streamer inception criteria[J]. High Voltage Apparatus,2017,53 (7):38-44.

郑宇,周文俊,陈维江,等.密闭空间中温度对SF 6 /N 2 混合气体工频击穿电压的影响规律[J ] .中国电机工程学报,2019,39 (15):4589-4598.

ZHENG Yu, ZHOU Wenjun, CHEN Weijiang, et al.Influence law of temperature on power frequency breakdown voltages of SF 6 /N 2 mixture in enclosed space[J ] . Proceedings of the CSEE,2019,39 (15):4589-4598.

陶亦然.温度对GIS缺陷局部放电特高频信号特征的影响[D].北京:华北电力大学,2018.

TAO Yiran.Influence of temperature on partial discharge UHF characteristics of GIS defects[D]. Beingjing:North China Electric Power University,2018.

郭壮. GIS中线性金属颗粒运动行为及温度影响的研究[D].北京:华北电力大学,2018.

GUO Zhuang.The motion behavior and temperature effect of linear metallic particles inGIS[D]. Beingjing:North China Electric Power University,2018.
